Hellion High Bay 100W 14000 lumens

EL100HFB
PRODUCT DATA
LUMENS (lm)
14000
lm
DIMMABLE
1-10
WATTAGE (W)
100W
COLOUR TEMPERATURE (K)
5000K
EMERGENCY
WEIGHT (kg)
7kg
MICROWAVE
BEAM ANGLE
110x120°
WINDAGE
CRI
>80
REPLACEMENT FOR
4x49W T5 high output
DIMENSIONS (mm)
1090x322x60mm
PRODUCT TYPE
High bays
EFFICIENCY (lm/w)
140lm/W
RATED LIFETIME (hrs)
50,000hrs
IP
20
WORKING ENVIRONMENT
-35°C to 35°C
L70 RATING (hrs)
DAYLIGHT HARVESTING
ON/OFF SENSOR
KEY FEATURES

An ideal replacement for MH or fluorescent Low Bays, the Hellion 14000 lumens is low glare with clear or frosted polycarbonate lenses, in-built emergency options housed in a lightweight and slimline, white, aluminium casing.

Commercial applications

Warehouse racking, manufacturing production, depots, airports, retails outlets, exhibition centres.

POLAR CURVE DIAGRAM
Polar Curve Image
CONE DIAGRAM
Cone Diagram
DIMENSIONS

Hellion High Bay 100W 14000 lumens

Hellion High Bay
Lumen output
Lumen output
Colour Temperature
Colour Temperature
Warranty
Warranty
KEy Features

An ideal replacement for MH or fluorescent Low Bays, the Hellion 14000 lumens is low glare with clear or frosted polycarbonate lenses, in-built emergency options housed in a lightweight and slimline, white, aluminium casing.

Commercial applications

Warehouse racking, manufacturing production, depots, airports, retails outlets, exhibition centres.

PHOTOMETRIC (LDT) FILES
PRODUCT DATA SHEET PDF
Notice for Microsoft Edge users
INSTALLATION instructions
LUMEN OUTPUT (lm)
14000
LUMEN OUTPUT RANGE (lm)
DIMMABLE
1-10
WATTAGE (W)
100W
COLOUR TEMPERATURE (K)
5000K
EMERGENCY
WEIGHT (kg)
7kg
MICROWAVE
BEAM ANGLE
110x120°
WINDAGE
CRI
>80
REPLACEMENT FOR
DIMENSIONS (mm)
1090x322x60mm
PRODUCT TYPE
High bays
EFFICIENCY (lm/w)
140lm/W
RATED LIFETIME (hrs)
50,000hrs
IP-RATING
20
WORKING ENVIRONMENT
-35°C to 35°C
L70 RATING (hrs)
DAYLIGHT HARVESTING
WARRANTY
5
ON/OFF SENSOR
