Ellipse 6" 12W Downlight Warm

EL612ED2W
KEY FEATURES

The Ellipse range of downlights are slimline, efficient and very simple to install - simply wire directly into the mains and clip into place. This versatile offering looks very attractive with a matt white bezel and an even diffused light. The Ellipse range can be used as the main source of light in a wide range of applications and will also perfectly compliment feature lighting and chandeliers without causing glare.

Commercial applications

Suitable locations include hotels, offices, bars, shops, restaurants hospitals and medical centres.

PRODUCT DATA
Lumens (lm)
800
Daylight HArvesting
No
Colour Temperature (K)
3000K
Dimmable
Dimmable-DALI
WATTAGE (W)
12W
Emergency
Emergency
WEIGHT (KG)
0.25kg
Microwave
No
Beam Angle
110°
On-Off Sensor
No
CRI
>80
Input Voltage
Dimensions (m
175Ø x 32mm (cut out 155mm Ø)
Windage
Efficiency (LM/W)
REPLACEMENT FOR
26W PL
IP
IP20
Product Type
Downlights
Working Environment
-20°C → 40°C
Rated Lifetime (Hours)
25000
L70 Rating
OTHER
DIMENSIONS
POLAR CURVE DIAGRAM
Polar Curve Image
CONE DIAGRAM
Cone Diagram

Ellipse 6" 12W Downlight Warm

Wattage
12
Lumen
800
Emergency
Beam Angle
110º
Colour Temperature
3000K
KEy Features

The Ellipse range of downlights are slimline, efficient and very simple to install - simply wire directly into the mains and clip into place. This versatile offering looks very attractive with a matt white bezel and an even diffused light. The Ellipse range can be used as the main source of light in a wide range of applications and will also perfectly compliment feature lighting and chandeliers without causing glare.

Commercial applications

Suitable locations include hotels, offices, bars, shops, restaurants hospitals and medical centres.

PHOTOMETRIC (LDT) FILES
PRODUCT DATA SHEET
INSTALLATION instructions
Lumens (lm)
800
Daylight HArvesting
No
Colour Temperature (K)
3000K
Dimmable
Dimmable-DALI
WATTAGE (W)
12W
Emergency
Emergency
WEIGHT (KG)
0.25kg
Microwave
No
Beam Angle
110°
On-Off Sensor
No
CRI
>80
Input Voltage
Dimensions (m
175Ø x 32mm (cut out 155mm Ø)
Windage
Efficiency (LM/W)
REPLACEMENT FOR
26W PL
IP
IP20
Product Type
Downlights
Working Environment
-20°C → 40°C
Rated Lifetime (Hours)
25000
L70 Rating
OTHER
