Barracuda 4ft 36W 4680 lumens dali-dimmable

EL1236BNCD
PRODUCT DATA
LUMENS (lm)
4680
DIMMABLE
Dimmable-DALI
WATTAGE (W)
36W
COLOUR TEMPERATURE (K)
5000K
EMERGENCY
WEIGHT (kg)
1.9kg
MICROWAVE
BEAM ANGLE
160°
WINDAGE
CRI
>80
REPLACEMENT FOR
Twin T5/T8 2x28W 4ft
DIMENSIONS (mm)
1220x100x82mm
PRODUCT TYPE
Non-corrosives
EFFICIENCY (lm/w)
130
RATED LIFETIME (hrs)
50,000hrs
IP
66
WORKING ENVIRONMENT
-40°C - 40°C
L70 RATING (hrs)
DAYLIGHT HARVESTING
KEY FEATURES

The 4ft Barracuda is lightweight and strong with anti-tamper, stainless steel clips and screws supplied. This product can be fitted in a wide range of industrial and commercial applications as its IP66 and IK08 ratings will ensure that it works in extreme environments. The dali dimmable driver gives total flexibility of the levels of light required.

Commercial applications

Public areas, workshops, warehouses, carparks and food preperation areas

POLAR CURVE DIAGRAM
Polar Curve Image
CONE DIAGRAM
Cone Diagram
DIMENSIONS

Barracuda 4ft 36W 4680 lumens dali-dimmable

lumen output
lumen output
4680
Colour temp
Colour temp
5000K
IP rating
IP rating
66
dali-dimmable
dali-dimmable
KEy Features

The 4ft Barracuda is lightweight and strong with anti-tamper, stainless steel clips and screws supplied. This product can be fitted in a wide range of industrial and commercial applications as its IP66 and IK08 ratings will ensure that it works in extreme environments. The dali dimmable driver gives total flexibility of the levels of light required.

Commercial applications

Public areas, workshops, warehouses, carparks and food preperation areas

PHOTOMETRIC (LDT) FILES
PRODUCT DATA SHEET PDF
INSTALLATION instructions
LUMENS (lm)
4680
DIMMABLE
Dimmable-DALI
WATTAGE (W)
36W
COLOUR TEMPERATURE (K)
5000K
EMERGENCY
WEIGHT (kg)
1.9kg
MICROWAVE
BEAM ANGLE
160°
WINDAGE
CRI
>80
REPLACEMENT FOR
Twin T5/T8 2x28W 4ft
DIMENSIONS (mm)
1220x100x82mm
PRODUCT TYPE
Non-corrosives
EFFICIENCY (lm/w)
130
RATED LIFETIME (hrs)
50,000hrs
IP
66
WORKING ENVIRONMENT
-40°C - 40°C
L70 RATING (hrs)
DAYLIGHT HARVESTING

Also available in this range

Product code
Product name
Wattage
Lumens
Colour temp.
Replacement for
